Key specs
- P2.5 outdoor LED display cabinet
- Cabinet 500 × 500 mm, 200 × 200 pixels
- Pixel pitch 2.5 mm, SMD Triad LED
- Brightness 4500 cd/m² (5000 cd/m² peak)
- Refresh rate 7680 Hz, grey level 14 bit
- Contrast ≥ 6000:1
- Front and rear maintenance
- IP66, working temperature -40 °C to 60 °C
- Power max. ≤ 510 W/m², average ≤ 170 W/m² (AC 220 V)
| Cabinet | |
|---|---|
| Pixel Configuration | SMD Triad LED |
| Pixel Pitch Category | P2.5 |
| Pixel Pitch | 2.5 mm |
| Modules Component | 2 × 2 |
| Dimensions (W × H × D) | 500 mm × 500 mm × 69 mm |
| Resolution | 200 × 200 |
| Area | 0.25 m² |
| Weight | 6.8 kg |
| Pixel Density | 160000 dots/m² |
| Lamp Board Housing | With housing |
| Cabinet Material | Aluminum |
| Maintenance Method | Front and rear maintenance |
| Protection Level | IP66 |
| Display | |
| White Balance Brightness | 4500 cd/m² (factory preset), 5000 cd/m² (peak) |
| Color Temperature | 9300 K adjustable |
| Viewing Angle | Horizontal 160°, vertical 160° |
| Contrast Ratio | ≥ 6000:1 |
| Color Uniformity | ≤ ± 0.003Cx, Cy |
| Brightness Uniformity | ≥ 97% |
| Processing Performance | |
| Driving Method | Constant current driving |
| Frame Frequency | 50/60 Hz |
| Refresh Rate | 7680 Hz |
| Grey Level | 14 bit |
| Key Material | |
| Lamp Encapsulation | 1415 |
| Control System | Hikvision |
| Power | |
| Power Supply | AC 110 to 220 V ± 15% |
| Max. Consumption | ≤ 510 W/m² (AC 220 V), ≤ 530 W/m² (AC 100 V) |
| Average Consumption | ≤ 170 W/m² (AC 220 V), ≤ 177 W/m² (AC 100 V) |
| Working Environment | |
| Working Temperature | -40 °C to 60 °C |
| Working Humidity | 10% RH to 90% RH |
| Accessory | |
| Optional | DS-D42MF2D, DS-D4225CE-1AP/M, DS-D42CE-PC/NC, DS-D42CE-PW, DS-D42CO-1/T (10 PCS), DS-D42CE22-1AP/H, DS-D42CE-1AP/R (5 PC), DS-D42CE-PC (5 PC), DS-D42CE-NC |
