LC1-MFDS

An LC1 loudspeaker is fitted into one housing, bought separately:

• LC1-MMSB mounting bracket: steel, 190 mm cut-out, ceilings up to 50 mm.
• LC1-CMR mounting ring: ABS, 200 mm cut-out, ceilings up to 25 mm. Always use it with the LC1-CBB back box.
• LC1-MFDS metal fire dome with grommets, 190 mm cut-out. The LC1-MFD fire dome with ceramic loop-through connector and the LC1-CSMB surface mounting box are available on request (ask us).

For EN54-24, use a fire dome, the surface mounting box, or the mounting ring with back box. Pilot tone indication and supervision boards are optional for every LC1 loudspeaker.

• LBC3080/01: steel fire dome, flame red RAL 3000, EN54-24 certified, for LBC3090/01, LBC3090/31, LHM0606/10, LHM0606/00, LHM0626/00 and LBC3087/41. A white version, LBC3080/11, is available (ask us).
• LBC3081/02: steel fire dome, flame red, for LBC3086/41. With it, the LBC3086/41 is EN54-24 certified.
• LC3-CBB: ABS back box for the LC3 range. The LC3-UC06E is EN54-24 only with it.
• LC1-MFDS metal fire dome, LC1-CMR mounting ring with LC1-CBB back box, or LC1-MMSB bracket: housings for the LC1 range.

The LC3-UM06E and the new Mid and Performance Level models have a metal fire dome built in.

Protechtors General Trading LLC (hik.ae) is an authorized partner of Bosch, Dynacord and Electro-Voice in the UAE, so everything we supply is genuine and comes with a 3-year warranty. Warranty is carry-in: bring the unit to our office in Dubai and after inspection it is repaired or replaced as needed.

We supply Bosch loudspeakers across the UAE and support you after the sale. Prices are quoted per project: tell us what you need and we will send a quote.
